欢迎来到《计算机视觉实战》系列教程的第八章。在第七章我们学习了CNN的基础知识，本章我们将深入学习当前最流行和最重要的现代CNN架构：ResNet和EfficientNet。

ResNet（Residual Network）在2015年提出，通过残差连接解决了深层网络训练困难的问题，是现代深度学习的重要里程碑。EfficientNet则通过复合缩放策略在效率和精度之间取得了最佳平衡。理解这些架构的设计思想，对于我们在实际项目中选择和优化模型至关重要。

---

1. 环境声明

• Python版本：Python 3.12+
• PyTorch版本：PyTorch 2.2+
• torchvision版本：0.17+
• NumPy版本：1.26+
• matplotlib版本：3.8+

---

2. ResNet：残差学习的革命

2.1 为什么需要残差连接

在ResNet之前，研究者们发现随着网络层数增加，训练误差反而变大，这种现象称为"退化问题"（Degradation Problem）。

退化问题的原因：深层网络难以学习恒等映射（identity mapping），即直接让H(x) = x。

残差学习的核心思想：不直接学习H(x)，而是学习F(x) = H(x) - x，然后H(x) = F(x) + x。

类比理解：学习"从A点到B点"很难，但学习"从A点走到B点需要移动多少"相对简单。残差就是这额外的"移动量"。

import torch
import torch.nn as nn
import torch.nn.functional as F

# 普通网络块 vs 残差块

class PlainBlock(nn.Module):
    """普通卷积块"""
    def __init__(self, in_channels, out_channels, stride=1):
        super().__init__()
        self.conv1 = nn.Conv2d(in_channels, out_channels, 3, stride=stride, padding=1, bias=False)
        self.bn1 = nn.BatchNorm2d(out_channels)
        self.conv2 = nn.Conv2d(out_channels, out_channels, 3, stride=1, padding=1, bias=False)
        self.bn2 = nn.BatchNorm2d(out_channels)
        self.relu = nn.ReLU(inplace=True)

    def forward(self, x):
        out = self.relu(self.bn1(self.conv1(x)))
        out = self.bn2(self.conv2(out))
        # 没有残差连接
        out = self.relu(out)
        return out


class ResidualBlock(nn.Module):
    """残差块"""
    def __init__(self, in_channels, out_channels, stride=1):
        super().__init__()
        self.conv1 = nn.Conv2d(in_channels, out_channels, 3, stride=stride, padding=1, bias=False)
        self.bn1 = nn.BatchNorm2d(out_channels)
        self.conv2 = nn.Conv2d(out_channels, out_channels, 3, stride=1, padding=1, bias=False)
        self.bn2 = nn.BatchNorm2d(out_channels)
        self.relu = nn.ReLU(inplace=True)

        # 残差连接
        self.shortcut = nn.Sequential()
        if stride != 1 or in_channels != out_channels:
            self.shortcut = nn.Sequential(
                nn.Conv2d(in_channels, out_channels, 1, stride=stride, bias=False),
                nn.BatchNorm2d(out_channels)
            )

    def forward(self, x):
        out = self.relu(self.bn1(self.conv1(x)))
        out = self.bn2(self.conv2(out))
        out += self.shortcut(x)  # 残差连接！
        out = self.relu(out)
        return out

# 验证两种block的行为差异
plain_block = PlainBlock(64, 64, stride=1)
residual_block = ResidualBlock(64, 64, stride=1)

x = torch.randn(1, 64, 56, 56)

print("普通块:")
plain_out = plain_block(x)
print(f"  输入形状: {x.shape}")
print(f"  输出形状: {plain_out.shape}")

print("\n残差块:")
residual_out = residual_block(x)
print(f"  输入形状: {x.shape}")
print(f"  输出形状: {residual_out.shape}")

# 测试恒等映射
print("\n恒等映射测试:")
x_identity = torch.randn(1, 64, 56, 56)

# 普通块
plain_out = plain_block(x_identity)
diff_plain = (plain_out - x_identity).abs().mean()
print(f"普通块 |F(x) - x|: {diff_plain:.6f}")

# 残差块
residual_out = residual_block(x_identity)
diff_residual = (residual_out - x_identity).abs().mean()
print(f"残差块 |H(x) - x|: {diff_residual:.6f}")

print("\n残差块更容易学习恒等映射！")

2.2 ResNet架构详解

import torch
import torch.nn as nn

class BasicBlock(nn.Module):
    """ResNet BasicBlock，用于ResNet-18/34"""
    expansion = 1

    def __init__(self, in_channels, out_channels, stride=1, downsample=None):
        super().__init__()

        self.conv1 = nn.Conv2d(in_channels, out_channels, 3, stride=stride, padding=1, bias=False)
        self.bn1 = nn.BatchNorm2d(out_channels)
        self.conv2 = nn.Conv2d(out_channels, out_channels, 3, stride=1, padding=1, bias=False)
        self.bn2 = nn.BatchNorm2d(out_channels)

        self.downsample = downsample
        self.relu = nn.ReLU(inplace=True)

    def forward(self, x):
        identity = x

        out = self.conv1(x)
        out = self.bn1(out)
        out = self.relu(out)

        out = self.conv2(out)
        out = self.bn2(out)

        if self.downsample is not None:
            identity = self.downsample(x)

        out += identity  # 残差连接
        out = self.relu(out)

        return out


class Bottleneck(nn.Module):
    """ResNet Bottleneck，用于ResNet-50/101/152"""
    expansion = 4  # 输出通道数扩展4倍

    def __init__(self, in_channels, out_channels, stride=1, downsample=None):
        super().__init__()

        # 1x1卷积降维
        self.conv1 = nn.Conv2d(in_channels, out_channels, 1, bias=False)
        self.bn1 = nn.BatchNorm2d(out_channels)

        # 3x3卷积
        self.conv2 = nn.Conv2d(out_channels, out_channels, 3, stride=stride, padding=1, bias=False)
        self.bn2 = nn.BatchNorm2d(out_channels)

        # 1x1卷积升维
        self.conv3 = nn.Conv2d(out_channels, out_channels * self.expansion, 1, bias=False)
        self.bn3 = nn.BatchNorm2d(out_channels * self.expansion)

        self.downsample = downsample
        self.relu = nn.ReLU(inplace=True)

    def forward(self, x):
        identity = x

        out = self.conv1(x)
        out = self.bn1(out)
        out = self.relu(out)

        out = self.conv2(out)
        out = self.bn2(out)
        out = self.relu(out)

        out = self.conv3(out)
        out = self.bn3(out)

        if self.downsample is not None:
            identity = self.downsample(x)

        out += identity
        out = self.relu(out)

        return out


class ResNet(nn.Module):
    """ResNet主干网络"""

    def __init__(self, block, layers, num_classes=1000):
        super().__init__()

        self.in_channels = 64

        # 初始卷积层
        self.conv1 = nn.Conv2d(3, 64, kernel_size=7, stride=2, padding=3, bias=False)
        self.bn1 = nn.BatchNorm2d(64)
        self.relu = nn.ReLU(inplace=True)
        self.maxpool = nn.MaxPool2d(kernel_size=3, stride=2, padding=1)

        # 残差层
        self.layer1 = self._make_layer(block, 64, layers[0], stride=1)
        self.layer2 = self._make_layer(block, 128, layers[1], stride=2)
        self.layer3 = self._make_layer(block, 256, layers[2], stride=2)
        self.layer4 = self._make_layer(block, 512, layers[3], stride=2)

        # 全局平均池化和分类器
        self.avgpool = nn.AdaptiveAvgPool2d((1, 1))
        self.fc = nn.Linear(512 * block.expansion, num_classes)

        # 权重初始化
        for m in self.modules():
            if isinstance(m, nn.Conv2d):
                nn.init.kaiming_normal_(m.weight, mode='fan_out', nonlinearity='relu')
            elif isinstance(m, nn.BatchNorm2d):
                nn.init.constant_(m.weight, 1)
                nn.init.constant_(m.bias, 0)

    def _make_layer(self, block, out_channels, blocks, stride=1):
        downsample = None
        if stride != 1 or self.in_channels != out_channels * block.expansion:
            downsample = nn.Sequential(
                nn.Conv2d(self.in_channels, out_channels * block.expansion, 1, stride=stride, bias=False),
                nn.BatchNorm2d(out_channels * block.expansion)
            )

        layers = []
        layers.append(block(self.in_channels, out_channels, stride, downsample))
        self.in_channels = out_channels * block.expansion

        for _ in range(1, blocks):
            layers.append(block(self.in_channels, out_channels))

        return nn.Sequential(*layers)

    def forward(self, x):
        x = self.conv1(x)
        x = self.bn1(x)
        x = self.relu(x)
        x = self.maxpool(x)

        x = self.layer1(x)
        x = self.layer2(x)
        x = self.layer3(x)
        x = self.layer4(x)

        x = self.avgpool(x)
        x = torch.flatten(x, 1)
        x = self.fc(x)

        return x


# 创建不同规模的ResNet
def resnet18():
    return ResNet(BasicBlock, [2, 2, 2, 2])

def resnet34():
    return ResNet(BasicBlock, [3, 4, 6, 3])

def resnet50():
    return ResNet(Bottleneck, [3, 4, 6, 3])

def resnet101():
    return ResNet(Bottleneck, [3, 4, 23, 3])

def resnet152():
    return ResNet(Bottleneck, [3, 8, 36, 3])

# 测试
print("ResNet各版本架构对比:")
print("=" * 60)

resnet_configs = {
    'ResNet-18': resnet18(),
    'ResNet-34': resnet34(),
    'ResNet-50': resnet50(),
    'ResNet-101': resnet101(),
    'ResNet-152': resnet152(),
}

for name, model in resnet_configs.items():
    model.eval()
    x = torch.randn(1, 3, 224, 224)

    # 计算参数量
    params = sum(p.numel() for p in model.parameters())

    # 计算FLOPs（近似）
    with torch.no_grad():
        output = model(x)

    print(f"{name}:")
    print(f"  参数量: {params:,} ({params/1e6:.1f}M)")
    print(f"  输出形状: {output.shape}")
    print()

2.3 ResNet的变体和改进

import torch
import torch.nn as nn
import torch.nn.functional as F

class PreActResidualBlock(nn.Module):
    """Pre-activation残差块 (ResNet v2)"""

    def __init__(self, in_channels, out_channels, stride=1):
        super().__init__()

        # 顺序改为 BN -> ReLU -> Conv
        self.bn1 = nn.BatchNorm2d(in_channels)
        self.conv1 = nn.Conv2d(in_channels, out_channels, 3, stride=stride, padding=1, bias=False)
        self.bn2 = nn.BatchNorm2d(out_channels)
        self.conv2 = nn.Conv2d(out_channels, out_channels, 3, stride=1, padding=1, bias=False)

        self.shortcut = nn.Sequential()
        if stride != 1 or in_channels != out_channels:
            self.shortcut = nn.Conv2d(in_channels, out_channels, 1, stride=stride, bias=False)

    def forward(self, x):
        out = F.relu(self.bn1(x))  # 先激活
        out = self.conv1(out)
        out = F.relu(self.bn2(out))
        out = self.conv2(out)
        out += self.shortcut(x)

        return out


class SEResidualBlock(nn.Module):
    """SE残差块 (Squeeze-and-Excitation)"""

    def __init__(self, in_channels, out_channels, stride=1, reduction=16):
        super().__init__()

        self.conv1 = nn.Conv2d(in_channels, out_channels, 3, stride=stride, padding=1, bias=False)
        self.bn1 = nn.BatchNorm2d(out_channels)
        self.conv2 = nn.Conv2d(out_channels, out_channels, 3, stride=1, padding=1, bias=False)
        self.bn2 = nn.BatchNorm2d(out_channels)

        # SE模块
        self.se = nn.Sequential(
            nn.AdaptiveAvgPool2d(1),
            nn.Flatten(),
            nn.Linear(out_channels, out_channels // reduction),
            nn.ReLU(inplace=True),
            nn.Linear(out_channels // reduction, out_channels),
            nn.Sigmoid()
        )

        self.downsample = None
        if stride != 1 or in_channels != out_channels:
            self.downsample = nn.Sequential(
                nn.Conv2d(in_channels, out_channels, 1, stride=stride, bias=False),
                nn.BatchNorm2d(out_channels)
            )

    def forward(self, x):
        out = F.relu(self.bn1(self.conv1(x)))
        out = self.bn2(self.conv2(out))

        # SE注意力
        se = self.se(out).view(out.size(0), out.size(1), 1, 1)
        out = out * se

        if self.downsample is not None:
            x = self.downsample(x)

        out += x
        out = F.relu(out)

        return out


# 测试SE块
se_block = SEResidualBlock(64, 128, stride=2)
x = torch.randn(1, 64, 56, 56)
out = se_block(x)
print(f"SE残差块输入: {x.shape}")
print(f"SE残差块输出: {out.shape}")

print("\nResNet改进方向:")
print("1. Pre-activation: BN-ReLU-Conv顺序，提高训练稳定性")
print("2. SE (Squeeze-and-Excitation): 通道注意力机制")
print("3. ResNeXt: 分组卷积，增加Cardinality")
print("4. DenseNet: 密集连接，每层接收所有前面层的特征")

---

3. EfficientNet：复合缩放的艺术

3.1 EfficientNet的设计思想

EfficientNet是2019年Google提出的新型CNN架构，核心思想是通过复合缩放（Compound Scaling）同时调整网络的深度、宽度和分辨率。

单维度缩放的问题：

• 只增加深度：训练困难，收益递减
• 只增加宽度：参数呈平方增长
• 只增加分辨率：感受野变大，但宽度没跟上

复合缩放公式：
$$depth:d={\alpha }^{\varphi }$$
$$width:w={\beta }^{\varphi }$$
$$resolution:r={\gamma }^{\varphi }$$

约束条件：$\alpha \times {\beta }^2\times {\gamma }^2\approx 2$，且 $\alpha \ge 1,\beta \ge 1,\gamma \ge 1$

import torch
import torch.nn as nn
import torch.nn.functional as F
import math

class Swish(nn.Module):
    """Swish激活函数：x * sigmoid(x)"""
    def forward(self, x):
        return x * torch.sigmoid(x)


class SEBlock(nn.Module):
    """Squeeze-and-Excitation模块"""
    def __init__(self, in_channels, se_ratio=0.25):
        super().__init__()
        reduced = max(1, int(in_channels * se_ratio))
        self.se = nn.Sequential(
            nn.AdaptiveAvgPool2d(1),
            nn.Flatten(),
            nn.Linear(in_channels, reduced, bias=False),
            Swish(),
            nn.Linear(reduced, in_channels, bias=False),
            nn.Sigmoid()
        )

    def forward(self, x):
        return x * self.se(x).view(x.size(0), x.size(1), 1, 1)


class MBConvBlock(nn.Module):
    """Mobile Inverted Residual Bottleneck Block"""

    def __init__(self, in_channels, out_channels, kernel_size=3,
                 stride=1, expand_ratio=1, se_ratio=0.25, drop_connect_rate=0.0):
        super().__init__()

        self.stride = stride
        self.drop_connect_rate = drop_connect_rate
        self.in_channels = in_channels
        self.out_channels = out_channels

        # 第一个1x1卷积（如果expand_ratio != 1）
        expanded_channels = in_channels * expand_ratio
        if expand_ratio != 1:
            self.expand_conv = nn.Sequential(
                nn.Conv2d(in_channels, expanded_channels, 1, bias=False),
                nn.BatchNorm2d(expanded_channels, momentum=0.01, eps=1e-3),
                Swish()
            )
        else:
            self.expand_conv = nn.Identity()

        # 深度可分离卷积
        self.depthwise_conv = nn.Sequential(
            nn.Conv2d(expanded_channels, expanded_channels, kernel_size,
                     stride=stride, padding=kernel_size//2, groups=expanded_channels, bias=False),
            nn.BatchNorm2d(expanded_channels, momentum=0.01, eps=1e-3),
            Swish()
        )

        # SE模块
        if se_ratio > 0:
            self.se = SEBlock(expanded_channels, se_ratio)
        else:
            self.se = nn.Identity()

        # 输出1x1卷积
        self.project_conv = nn.Sequential(
            nn.Conv2d(expanded_channels, out_channels, 1, bias=False),
            nn.BatchNorm2d(out_channels, momentum=0.01, eps=1e-3)
        )

        # 残差连接（仅当stride=1且输入输出通道相同时）
        self.use_residual = (stride == 1 and in_channels == out_channels)

    def forward(self, x):
        identity = x

        # Expansion
        out = self.expand_conv(x)

        # Depthwise Conv
        out = self.depthwise_conv(out)

        # SE
        out = self.se(out)

        # Project
        out = self.project_conv(out)

        # Drop connect
        if self.use_residual and self.drop_connect_rate > 0:
            out = out * (torch.rand_like(out[:, :1, :, :]) < self.drop_connect_rate).detach() / self.drop_connect_rate

        # Residual
        if self.use_residual:
            out = out + identity

        return out


def calculate_efficientnet_params():
    """EfficientNet各版本的缩放参数"""

    configs = {
        'B0': {
            'width_coef': (1.0, 1.0, 1.0, 1.0, 1.0, 1.0, 1.0),
            'depth_coef': (1.0, 1.0, 1.0, 2.0, 2.0, 3.0, 3.0),
            'resolution': (224, 240, 260, 300, 380, 456, 528),
            'depth_div': 8,
        },
        # B1-B7省略类似定义
    }

    print("EfficientNet-B0 网络配置:")
    print("=" * 60)
    print(f"{'Stage':<8} {'Operator':<20} {'Channels':<10} {'Layers':<8} {'Resolution':<10}")
    print("-" * 60)

    # 基于B0的典型配置
    stages_config = [
        (1, 'Conv3x3 + BN + Swish', 32, 1, 224),
        (2, 'MBConv1, 3x3', 16, 1, 224),
        (3, 'MBConv6, 3x3', 24, 2, 224),
        (4, 'MBConv6, 5x5', 40, 2, 224),
        (5, 'MBConv6, 3x3', 80, 3, 224),
        (6, 'MBConv6, 5x5', 112, 3, 224),
        (7, 'MBConv6, 5x5', 192, 4, 224),
        (8, 'MBConv6, 3x3', 320, 1, 224),
        (9, 'Conv1x1 + BN + Swish + GlobalPool', 1280, 1, 224),
    ]

    for i, (stage, op, channels, layers, res) in enumerate(stages_config):
        print(f"{i+1:<8} {op:<20} {channels:<10} {layers:<8} {res:<10}")

    print("\n复合缩放策略:")
    print("1. 基准网络B0使用神经架构搜索(NAS)得到")
    print("2. B1-B7通过复合缩放得到")
    print("3. 缩放系数满足: α×β²×γ²≈2，α≥1, β≥1, γ≥1")
    print("4. φ=1时，B0的系数: α=1.2, β=1.1, γ=1.15")

calculate_efficientnet_params()

3.2 EfficientNet vs ResNet 对比

import torch
import torchvision.models as models
import time

def compare_models():
    """对比EfficientNet和ResNet的性能"""

    models_to_compare = {
        'ResNet-18': models.resnet18(pretrained=False),
        'ResNet-50': models.resnet50(pretrained=False),
        'EfficientNet-B0': models.efficientnet_b0(pretrained=False),
        'EfficientNet-B1': models.efficientnet_b1(pretrained=False),
        'EfficientNet-B2': models.efficientnet_b2(pretrained=False),
    }

    print("模型参数量和计算量对比:")
    print("=" * 70)
    print(f"{'模型':<20} {'参数量':<15} {'Top-1 Acc':<15} {'FLOPS':<15}")
    print("-" * 70)

    reference_acc = {
        'ResNet-18': 69.8,
        'ResNet-50': 76.1,
        'EfficientNet-B0': 77.1,
        'EfficientNet-B1': 79.1,
        'EfficientNet-B2': 80.1,
    }

    for name, model in models_to_compare.items():
        params = sum(p.numel() for p in model.parameters())
        print(f"{name:<20} {params/1e6:>10.1f}M {reference_acc.get(name, 'N/A'):>12}% {params*2/1e9:>10.1f}G")

    print("\n关键洞察:")
    print("-" * 70)
    print("1. EfficientNet-B0参数量仅5.3M，却达到77.1%的准确率")
    print("2. ResNet-50有25.6M参数，但准确率只有76.1%")
    print("3. EfficientNet通过复合缩放，在效率和精度间取得更好的平衡")
    print("4. 对于移动端/边缘设备，EfficientNet是更好的选择")
    print("-" * 70)

compare_models()

---

4. 其他重要CNN架构

4.1 DenseNet：密集连接

import torch
import torch.nn as nn

class DenseBlock(nn.Module):
    """DenseNet的密集块"""

    def __init__(self, in_channels, growth_rate, num_layers):
        super().__init__()

        self.layers = nn.ModuleList()
        for i in range(num_layers):
            # 每个Dense层：BN -> ReLU -> Conv(1x1) -> Conv(3x3)
            self.layers.append(nn.Sequential(
                nn.BatchNorm2d(in_channels + i * growth_rate),
                nn.ReLU(inplace=True),
                nn.Conv2d(in_channels + i * growth_rate, growth_rate, 3, padding=1, bias=False)
            ))

    def forward(self, x):
        features = [x]
        for layer in self.layers:
            new_feature = layer(torch.cat(features, dim=1))
            features.append(new_feature)
        return torch.cat(features, dim=1)


class TransitionLayer(nn.Module):
    """DenseNet的过渡层，用于降维"""

    def __init__(self, in_channels, out_channels):
        super().__init__()
        self.conv = nn.Sequential(
            nn.BatchNorm2d(in_channels),
            nn.ReLU(inplace=True),
            nn.Conv2d(in_channels, out_channels, 1, bias=False),
            nn.AvgPool2d(2, 2)
        )

    def forward(self, x):
        return self.conv(x)


class DenseNet(nn.Module):
    """DenseNet-BC (Compression + Bottleneck)"""

    def __init__(self, growth_rate=32, block_config=(6, 12, 24, 16),
                 num_init_features=64, bn_size=4, num_classes=1000):
        super().__init__()

        # 初始特征层
        self.features = nn.Sequential(
            nn.Conv2d(3, num_init_features, 7, stride=2, padding=3, bias=False),
            nn.BatchNorm2d(num_init_features),
            nn.ReLU(inplace=True),
            nn.MaxPool2d(3, stride=2, padding=1)
        )

        # 密集块和过渡层
        num_features = num_init_features
        self.dense_blocks = nn.ModuleList()
        self.transitions = nn.ModuleList()

        for i, num_layers in enumerate(block_config):
            block = DenseBlock(num_features, growth_rate, num_layers)
            self.dense_blocks.append(block)
            num_features = num_features + num_layers * growth_rate

            if i != len(block_config) - 1:
                out_features = num_features // 2  # compression factor = 0.5
                self.transitions.append(TransitionLayer(num_features, out_features))
                num_features = out_features

        # 最终的BN和分类器
        self.final_bn = nn.BatchNorm2d(num_features)
        self.classifier = nn.Linear(num_features, num_classes)

    def forward(self, x):
        x = self.features(x)

        for i, block in enumerate(self.dense_blocks):
            x = block(x)
            if i < len(self.transitions):
                x = self.transitions[i](x)

        x = F.relu(self.final_bn(x))
        x = F.adaptive_avg_pool2d(x, (1, 1))
        x = torch.flatten(x, 1)
        x = self.classifier(x)

        return x

print("DenseNet核心思想:")
print("=" * 50)
print("1. 每层接收所有前面层的特征作为输入")
print("2. 特征拼接而非相加，保留更多信息")
print("3. 需要压缩(Compression)以控制通道数")
print("4. 参数量更少，泛化能力更强")
print("=" * 50)

4.2 MobileNet：轻量化网络

import torch
import torch.nn as nn
import torch.nn.functional as F

class DepthwiseSeparableConv(nn.Module):
    """深度可分离卷积：Depthwise + Pointwise"""

    def __init__(self, in_channels, out_channels, stride=1):
        super().__init__()

        # Depthwise: 每个通道单独卷积
        self.depthwise = nn.Sequential(
            nn.Conv2d(in_channels, in_channels, 3, stride=stride, padding=1,
                     groups=in_channels, bias=False),
            nn.BatchNorm2d(in_channels),
            nn.ReLU6(inplace=True)
        )

        # Pointwise: 1x1卷积改变通道数
        self.pointwise = nn.Sequential(
            nn.Conv2d(in_channels, out_channels, 1, bias=False),
            nn.BatchNorm2d(out_channels),
            nn.ReLU6(inplace=True)
        )

    def forward(self, x):
        x = self.depthwise(x)
        x = self.pointwise(x)
        return x


class MobileNetV1(nn.Module):
    """MobileNet V1: 使用深度可分离卷积大幅减少计算量"""

    def __init__(self, num_classes=1000):
        super().__init__()

        self.features = nn.Sequential(
            # 初始层
            nn.Conv2d(3, 32, 3, stride=2, padding=1, bias=False),
            nn.BatchNorm2d(32),
            nn.ReLU6(inplace=True),

            # 深度可分离卷积块
            DepthwiseSeparableConv(32, 64, stride=1),
            DepthwiseSeparableConv(64, 128, stride=2),
            DepthwiseSeparableConv(128, 128, stride=1),
            DepthwiseSeparableConv(128, 256, stride=2),
            DepthwiseSeparableConv(256, 256, stride=1),
            DepthwiseSeparableConv(256, 512, stride=2),
            DepthwiseSeparableConv(512, 512, stride=1),
            DepthwiseSeparableConv(512, 512, stride=1),
            DepthwiseSeparableConv(512, 512, stride=1),
            DepthwiseSeparableConv(512, 512, stride=1),
            DepthwiseSeparableConv(512, 1024, stride=2),
            DepthwiseSeparableConv(1024, 1024, stride=1),
        )

        self.avgpool = nn.AdaptiveAvgPool2d(1)
        self.classifier = nn.Sequential(
            nn.Dropout(0.25),
            nn.Linear(1024, num_classes)
        )

    def forward(self, x):
        x = self.features(x)
        x = self.avgpool(x)
        x = torch.flatten(x, 1)
        x = self.classifier(x)
        return x

# 对比普通卷积和深度可分离卷积
print("计算量对比:")
print("=" * 50)

# 普通卷积: D_K × D_K × M × N × D_F × D_F
# 深度可分离卷积: D_K × D_K × M × D_F × D_F + M × N × D_F × D_F

D_K = 3  # 卷积核大小
M = 64   # 输入通道
N = 64   # 输出通道
D_F = 14  # 特征图大小

conv_flops = D_K * D_K * M * N * D_F * D_F
depthwise_sep_flops = D_K * D_K * M * D_F * D_F + M * N * D_F * D_F

print(f"普通卷积: {conv_flops:,} FLOPS")
print(f"深度可分离卷积: {depthwise_sep_flops:,} FLOPS")
print(f"加速比: {conv_flops/depthwise_sep_flops:.2f}x")
print("\n这就是MobileNet如此轻量的秘密！")

---

5. 模型选择指南

5.1 根据场景选择模型

def model_selection_guide():
    """模型选择指南"""

    scenarios = [
        ("移动端/边缘设备", "MobileNetV3", "延迟敏感、算力有限"),
        ("通用图像分类", "EfficientNet-B0/B1", "精度与效率平衡"),
        ("高精度需求", "EfficientNet-B5/B7, ResNet-152", "追求最高精度"),
        ("实时检测/分割", "ResNet-18/34, MobileNetV3", "需要快速推理"),
        ("服务器端部署", "EfficientNet-B3/B4, ResNet-50", "可以使用GPU"),
        ("模型压缩/蒸馏", "MobileNetV3, EfficientNet-B0", "作为教师或学生模型"),
    ]

    print("模型选择指南:")
    print("=" * 80)
    print(f"{'场景':<20} {'推荐模型':<25} {'特点':<30}")
    print("-" * 80)

    for scenario, model, feature in scenarios:
        print(f"{scenario:<20} {model:<25} {feature:<30}")

    print("=" * 80)


def trade_off_analysis():
    """精度 vs 参数量 vs 计算量权衡分析"""

    data = [
        ("MobileNetV3-S", 2.5, 56),
        ("MobileNetV3-L", 5.4, 56),
        ("EfficientNet-B0", 5.3, 77),
        ("EfficientNet-B1", 7.8, 79),
        ("EfficientNet-B2", 9.2, 80),
        ("EfficientNet-B3", 12.2, 82),
        ("ResNet-18", 11.7, 70),
        ("ResNet-34", 21.8, 73),
        ("ResNet-50", 25.6, 76),
        ("ResNet-101", 44.5, 78),
    ]

    print("\n精度 vs 参数量权衡:")
    print("=" * 60)
    print(f"{'模型':<20} {'参数量(M)':<15} {'ImageNet Top-1(%)':<15} {'效率(Acc/MParam)':<15}")
    print("-" * 60)

    for name, params, acc in data:
        efficiency = acc / params
        print(f"{name:<20} {params:<15.1f} {acc:<15} {efficiency:<15.2f}")

    print("\n关键洞察:")
    print("1. EfficientNet系列在效率(精度/参数)上普遍优于ResNet")
    print("2. MobileNetV3适合极端资源受限场景")
    print("3. ResNet在精度上仍然有竞争力，且更易于实现和调试")
    print("4. 实际选择需要考虑硬件特性、推理库优化等因素")

trade_off_analysis()

---

6. 实战：使用预训练模型

6.1 PyTorch预训练模型使用

import torch
import torchvision.models as models
import torchvision.transforms as transforms
from PIL import Image
import matplotlib.pyplot as plt

def use_pretrained_model():
    """使用PyTorch预训练模型进行推理"""

    # 1. 加载预训练模型
    print("加载预训练ResNet-50...")
    model = models.resnet50(weights='IMAGENET1K_V1')
    model.eval()

    # 2. 预处理
    preprocess = transforms.Compose([
        transforms.Resize(256),
        transforms.CenterCrop(224),
        transforms.ToTensor(),
        transforms.Normalize(mean=[0.485, 0.456, 0.406],
                           std=[0.229, 0.224, 0.225])
    ])

    # 3. 加载并预处理图像
    # img = Image.open('example.jpg')
    # input_tensor = preprocess(img).unsqueeze(0)

    # 使用随机数据模拟
    input_tensor = torch.randn(1, 3, 224, 224)

    # 4. 推理
    with torch.no_grad():
        output = model(input_tensor)

    # 5. 后处理 - 获取top5预测
    probabilities = torch.nn.functional.softmax(output[0], dim=0)
    top5_prob, top5_indices = torch.topk(probabilities, 5)

    # ImageNet 1000类标签（需要加载实际的标签文件）
    # 这里假设有标签
    print("\nTop-5 预测:")
    print(f"  类别ID: {top5_indices.numpy()}")
    print(f"  概率: {top5_prob.numpy()}")

    return model

# 模型微调示例
def fine_tune_model():
    """迁移学习：微调预训练模型"""

    # 加载预训练模型
    model = models.resnet50(weights='IMAGENET1K_V1')

    # 替换最后的分类层
    num_features = model.fc.in_features
    num_classes = 10  # 假设有10个类别
    model.fc = nn.Linear(num_features, num_classes)

    # 冻结前面的层
    for name, param in model.named_parameters():
        if 'fc' not in name:  # 只训练fc层
            param.requires_grad = False

    # 统计可训练参数
    trainable_params = sum(p.numel() for p in model.parameters() if p.requires_grad)
    total_params = sum(p.numel() for p in model.parameters())
    print(f"\n迁移学习参数统计:")
    print(f"  可训练参数: {trainable_params:,} ({trainable_params/total_params*100:.2f}%)")
    print(f"  冻结参数: {total_params - trainable_params:,}")

    return model


print("预训练模型使用指南:")
print("=" * 60)
print("1. weights='IMAGENET1K_V1' 加载官方预训练权重")
print("2. weights=None 加载随机初始化权重")
print("3. 微调时通常只替换最后的分类层")
print("4. 数据集小时可以冻结大部分层，只训练少量层")
print("5. 数据集大时可以微调更多层，甚至整个网络")

6.2 模型性能基准测试

import torch
import torchvision.models as models
import time

def benchmark_model(model, input_shape=(1, 3, 224, 224), warmup=10, runs=100):
    """基准测试模型的推理速度"""

    device = torch.device('cuda' if torch.cuda.is_available() else 'cpu')
    model = model.to(device)
    model.eval()

    # 预热
    x = torch.randn(input_shape).to(device)
    for _ in range(warmup):
        with torch.no_grad():
            _ = model(x)

    # 计时
    if device.type == 'cuda':
        torch.cuda.synchronize()

    start = time.time()
    for _ in range(runs):
        with torch.no_grad():
            _ = model(x)
        if device.type == 'cuda':
            torch.cuda.synchronize()

    elapsed = time.time() - start
    avg_time = elapsed / runs

    return avg_time

def run_benchmark():
    """运行模型基准测试"""

    models_to_test = [
        ('ResNet-18', models.resnet18),
        ('ResNet-50', models.resnet50),
        ('EfficientNet-B0', models.efficientnet_b0),
        ('MobileNetV3-S', models.mobilenet_v3_small),
    ]

    print("模型推理速度基准测试:")
    print("=" * 60)
    print(f"{'模型':<20} {'CPU延迟(ms)':<15} {'GPU延迟(ms)':<15}")
    print("-" * 60)

    for name, model_fn in models_to_test:
        model = model_fn(weights=None)

        # CPU测试
        model_cpu = model.cpu()
        cpu_time = benchmark_model(model_cpu, warmup=5, runs=20)

        # GPU测试
        if torch.cuda.is_available():
            model_gpu = model.cuda()
            gpu_time = benchmark_model(model_gpu, warmup=10, runs=100)
            print(f"{name:<20} {cpu_time*1000:>10.2f} {gpu_time*1000:>10.2f}")
        else:
            print(f"{name:<20} {cpu_time*1000:>10.2f} {'N/A':<15}")

    print("=" * 60)
    print("\n测试说明:")
    print("- CPU: Intel i9-12900K")
    print("- GPU: NVIDIA RTX 3090")
    print("- 输入尺寸: 1x3x224x224")
    print("- 测试环境可能影响结果，仅供参考")

run_benchmark()

---

7. 避坑小贴士

常见错误1：混淆ResNet和ResNeXt

解释：

• ResNet：使用残差连接，基本卷积
• ResNeXt：使用残差连接 + 分组卷积（Cardinality）

# ResNeXt的分组卷积
class ResNeXtBlock(nn.Module):
    """ResNeXt瓶颈块，使用分组卷积"""

    def __init__(self, in_channels, out_channels, stride=1, cardinality=32, base_width=4):
        super().__init__()

        # width of group
        width = int(out_channels * (base_width / 64)) * cardinality

        self.conv1 = nn.Conv2d(in_channels, width, 1, bias=False)
        self.bn1 = nn.BatchNorm2d(width)

        self.conv2 = nn.Conv2d(width, width, 3, stride=stride, padding=1,
                              groups=cardinality, bias=False)  # 分组！
        self.bn2 = nn.BatchNorm2d(width)

        self.conv3 = nn.Conv2d(width, out_channels * 4, 1, bias=False)
        self.bn3 = nn.BatchNorm2d(out_channels * 4)

        self.relu = nn.ReLU(inplace=True)
        self.downsample = None
        if stride != 1 or in_channels != out_channels * 4:
            self.downsample = nn.Sequential(
                nn.Conv2d(in_channels, out_channels * 4, 1, stride=stride, bias=False),
                nn.BatchNorm2d(out_channels * 4)
            )

    def forward(self, x):
        # ... 标准残差块逻辑
        pass

常见错误2：忽略模型的实际输入尺寸

现象：模型在推理时与训练时使用不同尺寸，导致精度下降

正确做法：

# EfficientNet-B0 使用 224x224
# EfficientNet-B1 使用 240x240
# EfficientNet-B2 使用 260x260
# EfficientNet-B3 使用 300x300

# 不要随意更改输入尺寸，否则需要重新调整模型的复合缩放参数
# 如果必须使用不同尺寸，可以使用 Adaptive pooling 或 interpolation

常见错误3：BatchNorm在推理时忘记切换模式

现象：训练和推理时BatchNorm统计量不一致

正确做法：

# 训练模式
model.train()  # BatchNorm使用batch统计量
for images, labels in train_loader:
    outputs = model(images)

# 推理模式
model.eval()  # BatchNorm使用训练时的统计量
with torch.no_grad():
    for images, labels in test_loader:
        outputs = model(images)

---

8. 本章小结

通过本章的学习，你应该已经掌握了：

1. ResNet核心原理：理解了残差学习如何解决深层网络训练困难
2. ResNet架构变体：掌握了BasicBlock、Bottleneck以及各种改进
3. EfficientNet设计：理解了复合缩放策略的数学原理
4. 其他重要架构：了解了DenseNet、MobileNet的特点
5. 模型选择：能够根据场景选择合适的模型
6. 预训练模型使用：掌握了迁移学习和微调的实践方法
7. 性能基准测试：学会了评估模型的推理速度

一句话总结：ResNet的残差连接让极深网络的训练成为可能，而EfficientNet的复合缩放则展示了同时优化深度、宽度和分辨率的系统性方法。

---

9. 练习与思考

1. 残差连接：分析残差连接为什么能缓解梯度消失问题
2. 复合缩放：推导EfficientNet复合缩放的约束条件
3. 架构对比：在相同参数量下，比较ResNet和EfficientNet的性能
4. 模型压缩：探索知识蒸馏、量化和剪枝等模型压缩技术
5. 自定义模块：设计一个结合SE和残差连接的注意力模块

---

下一章预告：第9章《目标检测基础R-CNN家族》将带你学习目标检测的基础知识，从R-CNN到Fast R-CNN，理解两阶段检测器的原理。

---

如果本章内容对你有帮助，欢迎点赞、收藏和关注。有任何问题可以在评论区留言。
